nStructor
Specifications
nStructor is nScrypt's new Factory in a Tool (FiT) trainer. With XYZ travel of 274mm X 240mm X 160mm, nStructor™ mimics the broad and robust functionality of its 3Dn, 3Dx, and nRugged cousins, including features such as target view and process view cameras, but lacks their high-precision performance.
nStructor™ can be used right out of the box - plug it in, power it on, and start learning nStudio and everything that the nScrypt Factory in a Tool systems can do!
Specifications:
- Dimensions: 480 x 480 x 600 mm
- Weight: 110 lbs / 50 kg
- Electrical Supply: Single Phase, 120 VAC
Included accessories:
- Target view camera
- Vision Pit
- Cleaning station
- Enclosure lights
- USB Webcam
- Process view camera
- nT Dispense™
- nT Place™
- nT Extrude™
- nT Mill™
- nT Scan™
Capabilities:
- X/Y Accuracy: ± 50 µ
- X/Y Bidirectional Repeatability ± 30 µ
- X/Y Maximum Acceleration .5g (no load)
- X/Y Maximum Speed 300 mm/s
- X/Y Travel Range 274 x 240 mm
- X/Y Resolution 12.5 µ
- Z Accuracy ± 20 µ
- Z Bidirectional Repeatability ± 10 µ
- Z Maximum Speed 50 mm/s
- Z Travel Range 160 mm
- Z Resolution 2.5 µ
